034Motorsport Dynamic+ TCU Software Upgrade for AL552 ZF8 Transmission, B9/B9.5 RS4/RS5
034Motorsport is proud to offer Stage 2 TCU Software for B9/B9.5 Audi RS4 or RS5 models equipped with the AL552 8-Speed ZF8 transmission!
Flashed directly through your vehicle’s OBD-II port, 034Motorsport’s proprietary calibrations for the AL552 TCU safely and effectively optimize its operation for Stage 1/1+ Performance ECU Software The result is a noticeable improvement in acceleration, without sacrificing comfort or reliability.
034Motorsport's AL552 Performance Software was developed entirely in-house on 034Motorsport's Development B9 and B9.5 Audi RS5. The calibrations continue to be refined and tested on enthusiast-owned beta tester cars around North America.
034MOTORSPORT B9/B9.5 AUDI RS4/RS5 AL552 ZF8 STAGE DESCRIPTIONS:
Stage 1 (Included with Purchase of 034Motorsport EA839 ECU Tuning):
034Motorsport Stage 1 Transmission Performance Tuning Software for the AL552 is included in the Dynamic+ Tuning Bundle with our Stage 1/1+ ECU software.
The Dynamic+ ECU Tuning accurately reports torque values to the TCU to ensure that all safety systems are intact in both control units, and the added torque from tuning is properly adjusted for when driving/shifting, including all safety systems designed to protect the engine and transmission. This results in better shift quality as the transmission is not having to reduce engine torque or having to adapt to misreported inputs.
Stage 2:
The 034Motorsport Stage 2 Transmission Performance Tuning Software for the AL552 is designed to further improve the drivability and performance of your Dynamic+ Tuned Audi B9/B9.5 Audi RS4 or RS5. Dynamic+ Stage 2 TCU Software can be used with our Stage 1/1+ ECU software.
034Motorsport Stage 2 TCU Tuning further improves shifting performance and speed for casual and track driving in all driving modes. Dynamic+ Tuning also activates AMAX shifting to ensure the quickest and most efficient shifting strategies while launching your vehicle. These changes result in a significant improvement in acceleration, and lower 0-60 and ¼ mile times.
Stage 3:
The 034Motorsport Stage 3 Transmission Performance Tuning Software for the AL552 is designed to further improve the drivability and acceleration performance of your Stage 3 Dynamic+ Tuned Audi B9/B9.5 RS4 or RS5. Dynamic+ Stage 3 TCU Software is designed to be used with Dynamic+ Stage 3 ECU Software. 034Motorsport Stage 3 TCU Tuning further optimizes shift points under partial and full throttle to keep the TTE720 Turbochargers in their peak power band, and raises the redline to 7,200 for maximum performance with the larger turbocharger!
PERFORMANCE TCU STAGE 2 SOFTWARE FEATURES:
Improved Torque Management
- As with any automatic transmission vehicle, the ECU and TCU computers work synchronously to properly apply torque to the vehicle's drivetrain in a safe and reliable manner. Within both the ECU and TCU, there are factory safety tables that limit overall torque output based upon what the factory first tuned the car for. The ECU reports the output of torque from the engine to the TCU, and the TCU decides if this is suitable, or too much. If it is too much, the TCU will command the ECU to reduce torque output based upon its safety tables.
- 034Motorsport takes a holistic approach with its Dynamic+ Tuning, and aims to retain as many OEM safety protocols as possible. While it is possible to tune around the factory TCU torque limiters from the ECU side, this is done at the expense of torque safety features that are integral in keeping your transmission running safely. 034Motorsport’s calibrators tune the ECU to work with the TCU to provide accurate torque values, and recalibrate the appropriate safety ranges for the TCU. Taking these extra steps to retain OEM safety systems on the ECU and TCU side is just one of the many reasons that Dynamic+ software provides substantial yet reliable performance increases.
Optimized Shift Points
- In order to take advantage of the increased powerband from the turbochargers, Dynamic+ Tuning optimizes the shift points in all driving modes to maximize acceleration during wide open throttle scenarios.
Improved Shift Speeds
- To further enhance the acceleration of your Audi, the ZF8 shift times are dramatically decreased in all driving modes, which ultimately results in quicker acceleration. Shift times are now up to 70% faster!
- Shift pressures are also increased in Sport Mode to maximize performance. In Sport Mode, you will notice less lazy shifts, more firm shifts, which ultimately results in quicker acceleration.
AMAX Shifting
- AMAX Shifting is a shifting strategy that stands for “Acceleration Maximum.” These gear shifts are the fastest and quickest possible for optimal acceleration . These are activated in shifting after launching your vehicle from a stop using launch control.
- AMAX is now activated in the 4
- When in AMAX mode, line pressures in the transmission have been optimized to safely increase shift speeds.
Increased Launch Stall RPM
- The launch stall RPM has been raised for a significant increase in force, allowing you to get off the line as fast as possible.
Delay Time Between Launches Reduced
- The delay time between launch control activations has been shortened. This is useful when drag racing to heat up tires using launch control, and re-activate quickly before launching down the drag strip!
034MOTORSPORT STAGE 2 AL552 PERFORMANCE TCU SOFTWARE COMPARISON:
| STOCK TCU SOFTWARE | 034MOTORSPORT STAGE 1 PERFORMANCE TCU SOFTWARE | 034MOTORSPORT STAGE 2 PERFORMANCE TCU SOFTWARE | |
|---|---|---|---|
| Maximum Shift RPM | 6800 RPM | 6800 RPM (7200 in Manual Mode) | 6600 RPM (7200 in Manual Mode) |
| Torque Reporting from ECU | Yes | Yes | Yes |
| Torque Limits | Stock | Recalibrated for Higher ECU Output | Recalibrated for Higher ECU Output |
| Shift Speed | Suitable | Suitable | Fastest |
| Shift Points | Slower Acceleration | Slower Acceleration | Fastest Possible Acceleration |
034MOTORSPORT DYNAMIC+ END USER FLASHING KIT:
034Motorsport's Dynamic+ End User Flashing Kit allows customers to install their 034Motorsport Dynamic+ Performance Software themselves. In addition, End User Flashing allows Dynamic+ Performance Software customers to receive and install software updates and revisions, flash back to stock, or upgrade to the next stage of performance software for their vehicle.
Requirements for End User Flashing:
- Windows 10/11 Laptop with Available USB Port
- Power Supply for Laptop
- Secure Wired (Or Very Stable WiFi) High-Speed Internet Connection
- Battery Charger, 20AMP minimum (CTEK Brand recommended)
- Available Electrical Outlets
034Motorsport End User Flashing Kit Contents:
- 034Motorsport OBD-II Adapter
- USB-A to USB-B Cable
- Carrying Case
- User Credentials (Provided Via Email)
034Motorsport Dynamic+ Flashing Portal:
EMISSIONS DISCLAIMER
- This product is sold for racing use as well as use on vehicles not registered for on highway use.
- By purchasing this product, you understand that this product is sold for racing use as well as used on vehicles not registered for on highway use, and that it is not legal for use on highway or street vehicles.
WELCOME TO DYNAMIC+ TUNING!
034Motorsport's Dynamic+ Performance Software provides reliable horsepower and torque increases through driver-centric calibrations that elevate driving enjoyment and precision. The Dynamic+ Tuning Philosophy emphasizes safety and reliability, with the goal of optimizing power delivery without compromising the longevity of the engine and related components.
Included with the Purchase of Any Dynamic+ Tune:
- Easy Map Switching
- When purchasing any 034Motorsport staged tune, all octanes for that specific tune are included, as is the vehicle’s stock file.
- Switching files is easy when using the Dynamic+ Flashing Portal on your Windows 10/11 computer, with mobile support coming soon!
- World Class Tuning Support
- 034Motorsport’s World Class Tuning Support Team is available 5 days a week standing by to answer and assist with any questions you may have regarding your Dynamic+ Tune, recommended hardware upgrades, or help to diagnose any issues you may have with your vehicle while flashing, or after you’ve flashed.
- Advanced Technological Support
- The 034Motorsport Dynamic+ Tuning Suite also offers enhanced to users to allow users to datalog their Volkswagen or Audi to ensure that it is running properly. This logger is available to be used with our Tuning Support Team and is not designed to be reviewed by the end user.
