Product Description
034Motorsport Dynamic+ Performance Software for B7 Audi A4 2.0T FSI
034Motorsport Performance Software is now available for B7 Audi A4 models equipped with the EA113 2.0T FSI Longitudinal engine!
Flashed directly through your vehicle's OBD-II port, 034Motorsport’s proprietary calibrations for the Bosch MED9 ECU safely and effectively increase the power output of the 2.0T FSI engine. The result is a noticeable improvement in acceleration and throttle response, without any sacrifice in driveability or reliability.
034Motorsport's EA113 2.0T FSI Longitudinal Performance Software was developed entirely in-house on 034Motorsport's Development B7 Audi A4. The calibrations were then refined on multiple enthusiast-owned B7 Audi A4 2.0T FSI vehicles before release.
SOFTWARE FEATURES
 | |
 |
 | |
 |
 | |
 |
 | *No-Crackle Files Available Upon Request. Please Email info@itsnotstock.com for More Information* |
 |
034MOTORSPORT EA113 2.0T FSI LONGITUDINAL MED9 ECU PERFORMANCE SOFTWARE COMPARISON
| STAGE | FUEL | MAX HP | MAX TQ | MAX HP GAIN | MAX TQ GAIN | REV LIMITER | SPEED LIMITER |
|---|---|---|---|---|---|---|---|
| Stock | 91 Oct | 205 HP | 202 TQ | NA | NA | 6,800 RPM | 205kph |
| Stage 1 | 91 Oct | 246 HP | 287 TQ | 60 HP @ 3,900 RPM | 98 TQ @ 3,200 RPM | 7,100 RPM | ∞ |
| K04 Turbo | 91 Oct | 303 HP | 317 TQ | 103 HP @ 6,500 RPM | 123 TQ @ 3,500 RPM | 7,100 RPM | ∞ |
034MOTORSPORT EA113 2.0T FSI LONGITUDINAL MED9 ECU PERFORMANCE SOFTWARE STAGE DESCRIPTIONS
STAGE 1
034Motorsport Stage 1 Performance Software for the EA113 2.0T FSI engine is engineered to safely increase horsepower and torque with no hardware modifications required. 034Motorsport's proprietary calibrations increase boost while optimizing timing and fueling maps to extract additional power from the 2.0T engine.
Stage 1 Performance Software features a higher redline of 7,100 RPM, resulting in a broader, more usable powerband. In addition to power improvements, 034Motorsport's engineers spent a significant amount of time refining the throttle mapping in order to provide improved throttle response and allow for more precise throttle modulation and further control of the vehicle when driving on track.
K04 TURBO
034Motorsport K04 Performance Software for the EA113 2.0T FSI engine is engineered to safely increase horsepower and torque with the addition of a K04 Turbocharger, High-Flow Downpipe, Larger Injectors, and HPFP Upgrade. 034Motorsport's proprietary calibrations increase boost while optimizing timing and fueling maps to extract additional power from the 2.0T engine.
K04 Performance Software features a higher redline of 7,100 RPM, resulting in a broader, more usable powerband. In addition to power improvements, 034Motorsport's engineers spent a significant amount of time refining the throttle mapping in order to provide improved throttle response and allow for more precise throttle modulation and further control of the vehicle when driving on track.
034MOTORSPORT EA113 2.0T FSI LONGITUDINAL MED9 ECU PERFORMANCE SOFTWARE HARDWARE REQUIREMENTS
| STAGE | REQUIRED MODIFICATIONS | RECOMMENDED MODIFICATIONS |
|---|---|---|
| Stage 1 |
|
|
| K04 Turbo |
|
|
034MOTORSPORT DYNAMIC+ END USER FLASHING KIT:
034Motorsport's Dynamic+ End User Flashing Kit allows customers to install their 034Motorsport Dynamic+ Performance Software themselves. In addition, End User Flashing allows Dynamic+ Performance Software customers to receive and install software updates and revisions, flash back to stock, or upgrade to the next stage of performance software for their vehicle.
Requirements for End User Flashing:
- Windows 10/11 Laptop with Available USB Port
- Power Supply for Laptop
- Secure Wired (Or Very Stable WiFi) High-Speed Internet Connection
- Battery Charger, 20AMP minimum (CTEK Brand recommended)
- Available Electrical Outlets
034Motorsport End User Flashing Kit Contents:
- 034Motorsport OBD-II Adapter
- USB-A to USB-B Cable
- Carrying Case
- User Credentials (Provided Via Email)
034Motorsport Dynamic+ Flashing Portal:
EMISSIONS DISCLAIMER
- This product is sold for racing use as well as use on vehicles not registered for on highway use.
- By purchasing this product, you understand that this product is sold for racing use as well as used on vehicles not registered for on highway use, and that it is not legal for use on highway or street vehicles.
WELCOME TO DYNAMIC+ TUNING!
034Motorsport's Dynamic+ Performance Software provides reliable horsepower and torque increases through driver-centric calibrations that elevate driving enjoyment and precision. The Dynamic+ Tuning Philosophy emphasizes safety and reliability, with the goal of optimizing power delivery without compromising the longevity of the engine and related components.
Included with the Purchase of Any Dynamic+ Tune:
- Easy Map Switching
- When purchasing any 034Motorsport staged tune, all octanes for that specific tune are included, as is the vehicle’s stock file.
- Switching files is easy when using the Dynamic+ Flashing Portal on your Windows 10/11 computer, with mobile support coming soon!
- World Class Tuning Support
- 034Motorsport’s World Class Tuning Support Team is available 5 days a week standing by to answer and assist with any questions you may have regarding your Dynamic+ Tune, recommended hardware upgrades, or help to diagnose any issues you may have with your vehicle while flashing, or after you’ve flashed.
- Advanced Technological Support
- The 034Motorsport Dynamic+ Tuning Suite also offers enhanced to users to allow users to datalog their Volkswagen or Audi to ensure that it is running properly. This logger is available to be used with our Tuning Support Team and is not designed to be reviewed by the end user.
